Ubiquiti Edgeswitch Lite (ES-24-Lite)

Description

Model: ES-24-Lite

• (24) Gigabit RJ45 Ports

• (2) SFP Ports

• (1) Serial Console Port

• Non-Blocking Throughput: 26 Gbps

• Switching Capacity: 52 Gbps

• Forwarding Rate: 38.69 Mpps

• Maximum Power Consumption: 25W

• Rack- or Wall-Mountable

• Quiet, Fanless Operation

• DC Input Option (Redundant or Stand-Alone)

Advanced Switching
Technology for the Masses

 The EdgeSwitch Lite is a fully managed, Gigabit
switch, delivering robust performance and intelligent

switching for growing networks. The EdgeSwitch Lite offers an
extensive suite of advanced Layer 2 switching features and
protocols, and also provides Layer 3 routing capability.

Switching Performance

The EdgeSwitch Lite offers the forwarding capacity to
simultaneously process traffic on all ports at line rate without any
packet loss. For its total, non-blocking throughput, the 24-port models
support up to 26 Gbps, while the 48-port models support up to
70 Gbps.

Fiber Connectivity

The EdgeSwitch Lite provides fiber connectivity options for
your growing networks. The 24-port models include two SFP ports,
providing up to 1 Gbps uplinks.

Powerful Functionality

The EdgeSwitch Lite uses a sophisticated operating system that
provides basic switching features, and a variety of advanced features
including:

• MSTP/RSTP/STP

• VLAN, Private VLAN, Voice VLAN • Link Aggregation

• DHCP Snooping, IGMP Snooping

• TACACS+, RADIUS, 802.1X, MAC Filtering, ACL

• DiffServ, CoS • Static Routing, Policy-Based Routing
