Ubiquiti U6-MESH | Indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point

Ubiquiti U6-MESH | Indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point - Image 2

Ubiquiti U6-MESH | Indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point

Name: Ubiquiti U6-MESH | Indoor / outdoor dual band, WiFi 6 (802.11ax) mesh access point
Brand: Ubiquiti
SKU: U6-Mesh
Availability: InStock

Add to wishlist

Compare

₦339,857.20

The UniFi U6 Mesh is a high-performance, outdoor-rated WiFi 6 access point designed for mesh networking. It’s ideal for extending wireless coverage in homes, businesses, and other areas where a strong, reliable signal is needed.

Key features:

WiFi 6 technology: Offers faster speeds, greater capacity, and improved efficiency compared to previous WiFi standards.
Mesh networking: Creates a self-healing network where devices can automatically connect to the strongest signal, ensuring seamless coverage.
Outdoor durability: Weatherproof design with an IPX5 rating, making it suitable for outdoor use.
Powerful performance: Delivers an aggregate throughput of up to 5.3 Gbps, allowing for multiple devices to connect simultaneously without experiencing slowdowns.
Easy management: Can be easily configured and managed through the UniFi Network

Download Catalog

SKU: U6-Mesh Categories: Ubiquiti, Unifi Enterprise WIFI

Dimensions	1 × 1 × 1 cm
brands	Ubiquiti

?u=https%3A%2F%2Fcdn.ecomm.ui.com%2Fproducts%2F7b8f8da5-d684-4170-be1f-71b53af8d7f9%2Fc84638cd-e2ce-4bfe-9e98-b730af63149a

Mechanical
Dimensions	Ø48.5 x 159.5 mm (Ø1.9 x 6.3″)
Weight	400 g (14.1 oz)
Enclosure material	Polycarbonate, aluminum
Mount material	Polycarbonate
Weatherproofing	IPX5
Hardware
Networking interface	(1) GbE RJ45 port
Management interface	Ethernet Bluetooth
Power method	PoE
Power supply	UniFi PoE switch 48V, 0.32A PoE adapter (Included)
Supported voltage range	44—57V DC
Max. power consumption	13W
Max. TX power 2.4 GHz 5 GHz 6 GHz	22 dBm 26 dBm –
MIMO 2.4 GHz 5 GHz 6 GHz	2 x 2 (DL/UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) –
Max. data rate 2.4 GHz 5 GHz 6 GHz	573.5 Mbps (BW40) 4.8 Gbps (BW160) –
Antenna gain 2.4 GHz 5 GHz 6 GHz	3 dBi 5 dBi –
LEDs	White/blue
Button	Factory reset
Mounting	Wall, desktop, pole (Included) Ceiling (Optional)
Ambient operating temperature	-30 to 60° C (-22 to 140° F)
Ambient operating humidity	5 to 95% noncondensing
Certifications	CE, FCC, IC
Software
WiFi standards	802.11a/b/g/n/ac/ax (WiFi 6)
Wireless security	WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID	8 per radio
VLAN	802.1Q
Advanced QoS	Per-user rate limiting
Guest traffic isolation	Supported
Concurrent clients	300+
Zero wait DFS	Yes* *Supported with upcoming firmware versions
Supported Data Rates
802.11a	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b	1, 2, 5.5, 11 Mbps
802.11g	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n	6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)
802.11ac	6.5 Mbps to 3.4 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6)	7.3 Mbps to 4.8 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)
Application Requirements
UniFi Network	Version 6.2.51 and later
